The Lowly S-Type Thermocouple: Still the Right Tool for the Right Job

The S-type thermocouple doesn’t often headline discussions about industrial temperature sensing — and for good reason. It’s expensive, delicate, and outputs a relatively weak signal. But dismissing it entirely would be a mistake. For certain high-temperature, high-stability applications, it remains a solid, if underappreciated, choice — provided its limitations are understood and managed.

What Is an S-Type Thermocouple?

The Type S thermocouple is composed of two noble metal wires: one 100% platinum, and the other 90% platinum and 10% rhodium. It’s standardized under IEC 60584 and is commonly used in the range of 0°C to 1600°C, with the most stable performance typically observed between 600°C and 1300°C.

Its thermoelectric sensitivity is quite low — around 10.2 µV/°C at moderate temperatures — making it one of the least sensitive standard thermocouple types. For comparison, the more ubiquitous Type K generates about 41 µV/°C under similar conditions.

This low EMF output presents challenges: signal-to-noise ratios are poor, and even small sources of electrical noise or impedance mismatch can impact accuracy. Reliable use depends on appropriate instrumentation.

Known Limitations and Engineering Constraints

1. Signal Strength and Instrumentation Requirements

Due to its weak EMF output, the S-type requires:

High-impedance input circuitry (typically >1 MΩ)
Low-noise signal paths
Short or well-shielded cable runs

For instance, ACR’s SRX6 Thermocouple Logger — with 2 MΩ input impedance — are suitable for noble-metal thermocouples like Type S.

2. Contamination Sensitivity

Kerlin notes that platinum-based thermocouples are particularly susceptible to contamination by metallic and non-metallic vapors. Metallic sheaths, such as stainless steel or Inconel, can degrade performance:

“Metals from a sheath can diffuse to the thermocouple wire and contaminate it.” – Practical Thermocouple Thermometry, Thomas W. Kerlin

For this reason, high-purity alumina (Al₂O₃) ceramic protection tubes are strongly recommended when deploying S-type sensors at elevated temperatures.

3. Reducing Atmospheres

S-type thermocouples should not be used in reducing environments — conditions that lack sufficient oxygen and contain reactive gases like hydrogen, carbon monoxide, or hydrocarbons. These can aggressively react with the platinum, accelerating degradation and signal drift.

Common industrial sources of reducing environments include:

Vacuum heat treatment
Controlled atmosphere sintering
Some carburizing or annealing processes

4. Grain Growth and Chemical Attack

At extreme temperatures, platinum and platinum-rhodium wires undergo grain growth — a metallurgical process where the crystalline grains within the metal enlarge. This affects mechanical properties and can increase vulnerability to chemical attack.

“Types R and S are less useful than Type B at high temperature because they experience greater grain growth.” – Kerlin

While Type S is quite stable under moderate high temperatures, it is not ideal for prolonged exposure beyond 1500°C. In such cases, Type B (which has a higher rhodium content and better resistance to grain growth) may be a better long-term option.

Where the S-Type Still Excels

Despite its quirks, Type S offers a key strength: long-term stability in oxidizing environments at elevated temperatures. This makes it suitable for:

Glass and ceramics manufacturing
Metallurgical process monitoring
Kiln and furnace profiling
Pharmaceutical and aerospace validation work (e.g., AMS 2750 compliance)

In clean, controlled, oxidizing conditions — with the right insulation and instrumentation — the S-type provides remarkably stable output with less drift than base metal alternatives.

Instrument Compatibility and Resolution: What to Look For

Beyond high input impedance, S-type thermocouples demand sufficient resolution. With a total signal span of less than 18 mV across their entire range, they are ill-suited to low-resolution data acquisition systems. For example, a 12-bit ADC over a ±20 mV range offers step sizes near 5 µV, which may translate to half a degree per count — or worse if noise is present. Meaningful use requires at least 16-bit conversion and careful analog design.

The ACR SRX6 employs a 16-bit analog-to-digital converter and dedicates that resolution to the typical range of supported thermocouple types, including Type S. Combined with its 2 MΩ input impedance, it’s engineered to maintain both signal integrity and measurement resolution for low-EMF thermocouples.

Instrument Compatibility: What to Look For

If you're deploying S-type thermocouples with data loggers, check for:

High input impedance on the instrument (≥1 MΩ ideally)
Cold junction compensation (CJC) that’s stable and accurate
Proper shielding and filtering in analog front-end circuits

Not every logger is equipped to handle the combination of low signal and high sensitivity to noise that platinum thermocouples bring. If you're unsure, test your setup using a precision simulator or voltage reference in the appropriate microvolt range.

Final Thoughts

The S-type thermocouple isn’t for everyone — and it was never meant to be. It’s a specialized tool, appropriate for applications where high-temperature stability, repeatability, and chemical resistance matter more than speed or cost.

If you're working in oxidizing high-heat environments and can give the S-type the attention it deserves — proper housing, clean atmosphere, and the right logger — it’s still a reliable performer. Just don’t ask it to do what it wasn’t designed to do.
