Description
Elevate your process signals monitoring with the SRX7 data logger
Introducing the SRX7, a self-powered, multi-channel data logger meticulously designed for professionals in the electrical and process control industries. With the capability to monitor and record a wide range of popular process signals at rates from 20 samples per second to one sample every 24 hours, the SRX7 offers unmatched versatility and precision. Whether you're conducting compressor monitoring, SCADA troubleshooting, or ensuring environmental regulations compliance, the SRX7 provides the accuracy and reliability you need.
Download the product sheet to learn more about Smart Reader SRX7.
Versatile applications for comprehensive monitoring
The SRX7 is engineered to support a diverse array of monitoring and troubleshooting needs, including:
- Compressor Monitoring: Maintain optimal performance and efficiency of compressors.
- SCADA Troubleshooting: Quickly identify and resolve SCADA system issues.
- Current Output Recording: Accurately record current outputs from various sources.
- Environmental Monitoring: Track wind speed, water flow, pH levels, and tank levels.
- Process Control Troubleshooting: Diagnose and resolve process control issues.
- Compliance Monitoring: Ensure adherence to environmental regulations.
- Parameter Monitoring: Monitor a wide range of parameters through commercially available transducers.
Key features for enhanced performance and usability
The SRX7 data logger is packed with advanced features designed to deliver superior performance and ease of use:
- Extensive Data Storage: Capable of storing up to 1 million readings for comprehensive data collection.
- Visual Alarms: LED flashing alarm lights provide immediate visual alerts for warning and critical conditions.
- Two-Stage Alarming: Receive notifications for both warning and critical levels to stay proactive.
- High Precision: 16-bit resolution ensures precise measurements for accurate data analysis.
- NIST Calibration: Calibrate to NIST standards to achieve the highest measurement accuracy.
- Portable Equations: Enable faster downloads and collaboration with less user intervention.
- Simplified Reporting: Generate detailed reports with a single button click.
- Custom Configuration Wizards: Easily configure custom equations and settings for specific monitoring needs.
Why choose the SRX7 data logger?
When you choose the SRX7 data logger, you invest in a tool that offers robust functionality, precision, and ease of use tailored to the needs of the electrical and process control industries. With its comprehensive features and reliable performance, the SRX7 ensures you have the accurate data necessary to make informed decisions and maintain compliance. Each SRX7 comes with TRX Basic software and a Mini USB interface cable, providing all you need to start monitoring immediately.
Contact us
For more information about the SRX7 Data Logger and its applications in the electrical and process control industries, please get in touch with our team. We are here to support you in achieving the highest standards of monitoring and compliance.
+1(800) 663-7845 (8AM - 4:30PM PST)
Specifications
| Alarm Connector | Critical and Warning connections Maximum 15V Maximum 350mA |
| Battery | 3.6V Lithium Typical 3 years |
| Channel 0 - Internal Temp | Resolution: 0.01°C Range: -40°C - 85°C Accuracy: ± 0.3°C (0C to 70C) Accuracy: ± 1°C (-40C to 85C) |
| Channel 4-DC Voltage/Current | Resolution: 16-bit Range: 0 – 5V DC Input Impedance: ~ 1 Megohm OR Range: 0 – 25mA DC Input Impedance: 10 ohms Accuracy: ± 0.5% Full Scale |
| Channel 5 & 6 – DC Voltage | Input Impedance: ~ 1 Megohm Resolution: 16-bit Range: 0 – 5V DC Accuracy: ± 0.5% Full Scale |
| Channel 7 – DC Voltage | Input Impedance: ~ 1 Megohm Resolution: 16-bit Range: 0 – 10V DC Accuracy: ± 0.5% Full Scale |
| Channels 1 to 3 DC Current | Input Impedance: 10 ohms Resolution: 16-bit Range: 0 – 25mA DC Accuracy: ± 0.5% Full Scale |
| Clock Accuracy | ± 1 seconds per day |
| LED Status & Alarm Lights | High & Low thresholds per channel Latch / Self-reset |
| Memory Size | 1 Million Readings |
| Operating Limits | -40°C to 85°C (-40°F to 185°F) 0 to 95% RH non-condensing |
| Sample Rates | 10s to 24 hours (normal mode) 50 mins to 10 s (powered fast mode) |
| Sampling Methods | Continuous (first-in-first-out) / Stop when full Immediate start / Delayed start - up to 2 months Spot / Averaged Readings |
| Size | 111 mm (4 3/8") x 74mm (2 15/16") x 27 mm (1 1/16") |
| Status Indicator | Flash rate: 10 seconds Green: logging Blue: delayed start Yellow: alarm warning Red: critical alarm Magenta: memory full |
| Weight | 140g (5 oz) |
Q&A
Click here to visit our NEW Q&A pages.Calibration
Data loggers are often used in highly regulated environments such as food and pharmaceutical production and storage where strict safety regulations apply. Regulatory agencies generally require proof of calibration.
ACR calibrations are performed using reference standards that have been calibrated and are traceable to the US National Institute of Standards & Technology (NIST). This ensures that all ACR data loggers meet, and perform to, their published specifications, allowing you to be confident that they will assist you in achieving your compliance requirements.
Calibration certificates are provided with every calibration we perform. ACR Systems is an ISO 9001:2015 registered company and calibration records are kept as part of our quality system and can be made available for customer audits.
