SRX8 is ideal for quick and accurate temperature recordings in up to 8 different locations simultaneously. Includes TRX Basic software and Mini USB interface cable.
SKU: 02-0400
$969.00 USD

Guaranteed safe checkout

american expressdiners clubdiscovermasterpaypalvisa

Description

SRX8 is ideal for quick and accurate temperature recordings in up to 8 different locations simultaneously.  Includes TRX Basic software and Mini USB interface cable.

Typical applications include:

  • Pharmaceutical manufacturing and Vaccine storage
  • Pest heat treatment
  • Storage conditions of perishable items
  • Building comfort monitoring
  • Food process verification
  • Back-up system monitoring for storage and transport

Key Features:

  • Can connect up to 7 external temperature Thermistors
  • Equipped with one internal  ambient temperature channel
  • Capable of storing up to 1 million readings
  • LED flashing alarm lights
  • Two-stage alarming (Warning & Critical)
  • 12-bit resolution provides greater accuracy  to achieve the highest possible measurement quality
  • Portable equations onboard the data logger ensure faster downloads and collaboration with less user intervention
  • One-button report generation. Wizards for Equations and programming = ease of use
  • Can be calibrated to NIST standards

 SRX8 Product Sheet

Specifications

Alarm Connector Critical and Warning connections
Maximum 15V
Maximum 350mA
Battery 3.6V Lithium
Typical battery life: 10 years under normal operating conditions @ 25°C
Channel 0 - Internal Temp Resolution: 0.01°C
Range: -40°C - 85°C
Accuracy: ± 0.3°C (0C to 70C)
Accuracy: ± 1°C (-40C to 85C)
Channels 1-7 - Thermistor Resistance Range: 500 ohm to 400K ohm
Clock Accuracy ± 1 seconds per day
LED Status & Alarm Lights High & Low thresholds per channel
Latch / Self-reset
Memory Size 1 Million Readings
Operating Limits 0 to 95% RH non-condensing
0 to 95% RH non-condensing

Sample Rates 10s to 24 hours
Sampling Methods Continuous (first-in-first-out) / Stop when full
Immediate start / Delayed start - up to 2 months
Spot / Averaged Readings
Size 111 mm (4 3/8") x 74mm (2 15/16") x 27 mm (1 1/16")
Status Indicator Flash rate: 10 seconds
Green: logging
Blue: delayed start
Yellow: alarm warning
Red: critical alarm
Magenta: memory full
Warranty 3 years
Weight 140g (5 oz)

Software

ACR softwares are powerful, easy and intuitive that opens a window into the analysis of your data collected. Data can be viewed in various formats and presentation quality graphs can be exported into any WORD program. The software provides electronic records for a reduced paper trail.

Documentation

For a product sheet, please click below for a pdf version.

Product Sheet

Q&A

Click here to visit our NEW Q&A pages.

Calibration

Data loggers are often used in highly regulated environments such as food and pharmaceutical production and storage where strict safety regulations apply. Regulatory agencies generally require proof of calibration.

ACR calibrations are performed using reference standards that have been calibrated and are traceable to the US National Institute of Standards & Technology (NIST). This ensures that all ACR data loggers meet, and perform to, their published specifications, allowing you to be confident that they will assist you in achieving your compliance requirements.

Calibration certificates are provided with every calibration we perform. ACR Systems is an ISO 9001:2015 registered company and calibration records are kept as part of our quality system and can be made available for customer audits.

Calibration Service
